Description Features Specifications Search Contact Us Features Frequency Band HF 13.56 MHz Chip Type NXP ICODE® SLIX International Standard ISO/IEC 15693, ISO/IEC 18000-3, NFC Forum Tag Type 5 User Memory 896 bits Read Range Up to 1.5 m Certificate WEEE compliant Specifications PRODUCT DATASHEET NXP ICODE® SLIX Datasheet Physical Specifications Material: Coated PaperLabel Size: 50×50 mmAntenna Size: 45×45 mm Technical Parameters Operating Frequency: 13.56 MHzCommunication Protocol:ISO/IEC 15693, ISO/IEC 18000-3, NFC Forum Tag Type 5Read Range: Up to 1.5 mCapacitance: 23.5 pFOperating mode: Passive Chip Characteristics Chip Manufacturer: NXP®Chip Type: ICODE® SLIXData Retention: 50 yearsUser memory: 896 bitsTID memory: 64 bitsWrite Endurance: 100,000 cyclesReading Rate: 53 kbit/sHigh data integrity: 16-bit CRCLock mechanism: EAS, AFI, DSFIDAnti-Collision Function: YesPassword: 32-bit protected EAS and AFI functionality Additional Information Operating Environment:Label attach: 10°C ~ 40°C, 20% ~ 80% RHAfter label attached: -20°C ~ 50°C, 20% ~ 80% RHStorage Environment: 18°C ~ 28°C, 40% ~ 60% RHHandling Precautions:1. Do not bend.2. Keep away from water and collision.3. Labels with black-dot marks are bad ones, do not use. Packaging Packing Format: Packed in roll, vacuumed packing in ESD bagRoll OD: Max. 203.2 mmCore ID: 3 inch (76.20 ± 0.50 mm)Packing Quantity: 1000 Pcs/roll, per roll 0.803 kg No More Checkout Lines: Gramedia Uses RFID for Instant Book Checkout RFID Library Labels Watch this video on YouTube Difference Between NXP ICODE® SLIX There are four ICs within NXP ICODE® SLIX family, that ICODE® SLIX, ICODE® SLIX2, ICODE® SLIX-L and ICODE® SLIX-S. The difference in between is mainly the size of EEPROM. ICODE® SLIX is the only type of IC DOES NOT support EAS selection and memory protection. NXP ICODE® SLIX Unique Identifier (UID): 64 bits User Memory: 896 bits EEPROM: 1024 bits, organized in 32 blocks of 4 bytes each Operating frequency: 13.56 MHz Operating distance: Up to 1.5 meter Data Transfer Rate: Up to 53 kbit/s Communication Protocol: ISO15693, ISO18000-3, NFC Forum Tag 5 Type Input capacitance: 23.5 pF / 97 pF Lock mechanism for DSFID, AFI, EAS Password (32-bit) protected EAS and AFI functionality anti-collision: Yes Data retention: 50 years Write endurance: 100,000 cycles NXP ICODE® SLIX2 Unique Identifier (UID): 64 bits User Memory: 2528 bits EEPROM: 2560-bit user memory, 80 blocks of 4 bytes each Operating frequency: 13.56 MHz Operating distance: Up to 1.5 meter Data Transfer Rate: Up to 53 kbit/s Communication Protocol: ISO15693, ISO18000-3, NFC Forum Tag 5 Type Input capacitance: 23.5 pF Lock mechanism for DSFID, AFI, EAS Password (32-bit) protected EAS and AFI functionality Password (32-bit) protected Label Destroy Password (32-bit) protected Privacy Mode anti-collision: Yes Data retention: 50 years Write endurance: 100,000 cycles NXP ICODE® SLIX-L Unique Identifier (UID): 64 bits User Memory: 256 bits EEPROM: 512 bits, organized in 16 blocks of 4 bytes each Operating frequency: 13.56 MHz Operating distance: Up to 1.5 meter Data Transfer Rate: Up to 53 kbit/s Communication Protocol: ISO15693, ISO18000-3, NFC Forum Tag 5 Type Input capacitance: 23.5 pF / 97 pF Lock mechanism for DSFID, AFI, EAS Password (32-bit) protected EAS and AFI functionality Password (32-bit) protected Label Destroy Password (32-bit) protected Privacy Mode anti-collision: Yes Data retention: 50 years Write endurance: 100,000 cycles NXP ICODE® SLIX-S Unique Identifier (UID): 64 bits User Memory: 1280 bits EEPROM: 2048 bits (2 KB), organized in 64 blocks of 4 bytes each Operating frequency: 13.56 MHz Operating distance: Up to 1.5 meter Data Transfer Rate: Up to 53 kbit/s Communication Protocol: ISO15693, ISO18000-3, NFC Forum Tag 5 Type Input capacitance: 23.5 pF / 97 pF Lock mechanism for DSFID, AFI, EAS Password (32-bit) protected EAS and AFI functionality Password (32-bit) protected Label Destroy Password (32-bit) protected Privacy Mode anti-collision: Yes Data retention: 50 years Write endurance: 100,000 cycles Loooking for More Products? search or use the categories Search for: Search Labels By Functions Labels By IC Type Labels By Frequency Labels by Shape RFID Reader and Antenna RFID Printer Why Choose us QUALITY & VALUE As a leading RFID hardware manufacturer for over a decade, we are committed to delivering unparalleled quality at competitive prices. Our advanced production facilities and stringent quality control ensure that every product meets the highest standards. EXPERTISE & INNOVATION Our expert team drives innovation in RFID technology. Whether you need custom solutions or cutting-edge products, we provide advanced and effective RFID solutions tailored to your needs. EFFICIENT & RELIABILITY We offer reliable global shipping with in-stock items delivered within 1-3 business days in North America, Europe, and the Asia Pacific. Our proven track record ensures your satisfaction every time. Ask How We can Help Name * Email * Company Message Send RFID Readers to Match ISO 15693 Compliant High Power Desktop HF RFID Reader ACS® ACR1552U Desktop HF NFC Reader HF RFID Reader RD5230 ISO15693 and ISO18000-3M1 HF RFID Reader RD5224 ISO15693 and ISO18000-3M1 Multi-Protocol Desktop HF RFID Reader / Writer Desktop HF ISO15693 RFID Reader / Writer AZ-RL173 Fixed RFID Readers ISO 15693
